LiFePo4 battery 12V 20AH
Specially designed LiFePo4 batteries usable for more than 3000 cycles at 80% deph of discharge
Technical data:
Technical data:
- Nominal voltage 12 V
- Capacity 20 AH +/- 5%
- Operating voltage max 14.6V - min 10.8V At 100% DOD
- Deep discharge voltage 10,8V V The cells is damaged if voltage drops bellow this level
- Maximal charge voltage 14,6 V The cells is damaged if voltage exceeds this level
- Optimal discharge current less 10 A 0.5 C
- Maximal discharge current less 30 A 1.5 C, continuous for max 20 minutes from full charge
- Max peak discharge current less 80 A 10 C, maximal 10 seconds in 1 minute
- Optimal charge current less 10 A 0.5 C
- Maximal charge current less 20 A less 1 C with battery temperature monitoring
- Maximal continuous operating temperature 80 °C The battery temperature should not increase this level during charge and discharge
- Dimensions 181x 77 x 167 Millimeters (tolerance +/- 2 mm)
- Weight 3.3 kg Kilograms (tolerance +/- 150g)
