Orcafin NX-800
Version

starting from 159,00 €

including 19% VAT. , plus shipping

There are variations of this item. Please select the variation you wish.


Developement - Production - Quality - Made in Germany

With Orcafin NX-800 all different 12V trolling motors up to 800W power can be upgraded to variable speed. This includes all 12V brush motors on the market with usually up to 65lbs thrust. Examples are the 12 volts motor models named Rhino VX 54, Minn Kota Endura C2 or Haswing Osapian up to 55lbs thrust

Please use our special motor specific kits

Technical details:

  • 60 Amp long time; 80 Amp short time
  • Full speed forward and backward
  • Over temperature protection to 10% speed
  • Over current protection
  • No motorpiping
  • Soft Motorstart
  • Soft forward/backward switch
  • Motorschonendes An- und Umschalten
  • Komplett relaisfrei
  • Dismantalable
  • Robust Layout
  • Made in Germany
  • No switch delays - instant power
  • No start speed - go as slow as you like
  • Microprocessor controlled
  • Waterproof coating
  • Start protection
  • Learnable control lengh i.e. end points for full power
  • Supersoft control
  • Extreme energy savings of 60% compared to 1st speed
  • Measures 80 x 40 x 40 mm
  • Only 50g weight
  • Compatible for almost all 12volts trolling motors
  • Assembly in less than 10 minutes

With Orcafin NX you can upgrade your existing 5-speed switch controlled trolling motor to variable speed and save up to 60% energy!

If you have a trolling motor with 54lbs thrust you can see the energy saved by replacing the original 5/3 speed motor switch with Orcafin NX in the following table.

Ampere draw Rhino VX 54 (540 watts)

Speed

Original switch

Orcafin NX-800

Energy saving

(1. Speed) 2,2kmh 9,0 Amp 3,9 Amp 57 %
(2. Speed) 2,4kmh 10,6 Amp 5,8 Amp 45 %
(3. Speed) 3,0kmh 18,5 Amp 11,0 Amp 40 %
(4. Speed) 3,6kmh 21,5 Amp 13,6 Amp 37 %
(5. Speed) 5,0kmh 42,6 Amp 41,0 Amp 2 %
